Building fire safety systems

AlarmSense is a range of conventional detection and alarm products specially designed to be connected to the same pair of supply wires. The optical smoke detector uses an internal pulsing LED and a photodiode at an obtuse angle. In the event of smoke entering the chamber, the light pulse from the LED will be scattered and registered by the

Apollo manufactures Interfaces, a comprehensive range of intelligent systems. They enable fire protection systems to be engineered simply and effectively without the need for custom-designed equipment. The switch monitor is designed to monitor the state of one or more single-pole, volt-free contacts and report the status to Apollo compatible

The Discovery intelligent heater base is designed to be used in cold climates where environmental conditions could result in either icing or condensation affecting the operation of detectors

AlarmSense is a range of conventional detection and alarm products specially designed to be connected to the same pair of supply wires. The integrating optical smoke detector uses an internal pulsing LED and a photodiode at an obtuse angle. In the event of smoke entering the chamber, the light pulse from the LED will be scattered and registered by

The Series 65 range of conventional detectors incorporates well-proven sensing technologies, together with advances in materials and electronics technology. The Series 65 12V relay base is designed for use in both fire and security systems. For fire systems, a jumper on the PCB is fitted to a latching position. For security systems the jumper is

AlarmSense is a range of conventional detection and alarm products specially designed to be connected to the same pair of supply wires. Providing an alarm between 70 and 87dB(A), the AlarmSense sounder beacon base will detect the removal of a detector head and report a fault. It continues to work during unauthorised removal of detectors. Quick and

XPander is a wireless intelligent detector range in which individual alarm devices communicate with the XP95 loop by radio signals. Every device is assigned an address and this address is recognised by the control panel in the same way as is the address of any device connected directly to the loop wiring. The XPander sounder beacon and sounder

XPander is a wireless intelligent detector range in which individual alarm devices communicate with the XP95 loop by radio signals. Every device is assigned an address and this address is recognised by the control panel in the same way as is the address of any device connected directly to the loop wiring. The XPander sounder and sounder base is a

The Series 65 range of conventional detectors incorporates well-proven sensing technologies, together with advances in materials and electronics technology. The Series 65 standard mounting base has been designed to enable detectors to be fitted without the need of force. It is particularly useful when fitting to suspended ceilings. All Series 65

XPander is a wireless intelligent detector range in which individual alarm devices communicate with the XP95 loop by radio signals. Every device is assigned an address and this address is recognised by the control panel in the same way as is the address of any device connected directly to the loop wiring. The XPander rate-of-rise heat detector

The AlarmSense range of conventional detection and alarm products is specially designed to be connected to the same pair of supply wires. The AlarmSense alarm relay enables devices such as beacons, pillow/bed alarms and radio vibrating or paging devices to be connected to the fire detection system. This can help systems comply with the

AlarmSense is a range of conventional detection and alarm products specially designed to be connected to the same pair of supply wires. The AlarmSense sounder base is fitted with electronic circuitry to monitor the presence of detectors and signals any unauthorised removal of detector heads. It is supplied with a high or low volume setting and

The XP95 optical detector uses an internal pulsing LED and a photo-diode at an obtuse angle. In the event of smoke entering the chamber, the light pulse from the LED will be scattered and registered by the photo-diode. A signal is generated and transmitted digitally to the control equipment

The Series 65 range of conventional detectors incorporates well-proven sensing technologies, together with advances in materials and electronics technology. The Series 65 auxiliary relay base provides two sets of volt-free changeover contacts to facilitate the switching of a remote LED or other auxiliary device. Features: Advanced electronic

The Series 65 range of conventional detectors incorporates well-proven sensing technologies, together with advances in materials and electronics technology. The Series 65 end-of-line (EOL) relay base is intended for use with four-wire circuits. It features two sets of changeover contacts and a power supervision relay. Features: Advanced electronic

AlarmSense is a range of conventional detection and alarm products specially designed to be connected to the same pair of supply wires. AlarmSense mounting bases are specifically designed for the mounting of AlarmSense detectors. They are fitted with electronic circuitry to monitor the presence of detectors and allow a fault to be signalled if a

KAC offers a large range of call points which can be conventional or analogue addressable and surface or flush-mounted. The MCP range is designed to reduce installation time, by using a special terminal block connected to the back of the call point, where all initial installation cabling is terminated. MCP call points can be configured as either

WCP outdoor call points are designed for use in extreme weather conditions, with an operating temperature range of -30°C to +70°C. WCP models are available with configurations compatible with all conventional panels and intelligent versions are offered to meet specific requirements. The WCP range is approved to EN 54-11: most products are offered

The Discovery optical smoke detector uses an IR LED that pulses light across a smoke chamber with a photodiode set at an obtuse angle. In clear air it receives no light, but when smoke enters the chamber, light from the LED is scattered onto the photodiode. A signal is then processed to provide an analogue value for transmission when the detector

KACs analogue addressable range of audible visual alarms has been designed to meet the requirements of modern intelligent fire systems. The alarms can be installed as traditional wall-mounted devices or as detector base devices. A separate, common installation base is installed to allow simple twist fit of the AV device. This has a shorting spring

The XP95 multisensor detector contains an optical smoke sensor and a thermistor temperature sensor whose outputs are combined to give the final analogue value

Apollo manufactures Interfaces, a comprehensive range of intelligent systems. They enable fire protection systems to be engineered simply and effectively without the need for custom-designed equipment. The DIN-rail output unit provides a voltage-free single-pole, change-over relay output. It is a simplified version of the input/output unit without

The Discovery heat detector, distinguishable by a low airflow resistant case, uses a single thermistor to sense the air temperature around the detector. The thermistor is connected in a resistor network, which produces a voltage output dependent on temperature

The Discovery multisensor detector contains an optical smoke sensor and a thermistor temperature sensor whose outputs are combined to give the final analogue value. The multisensor is useful over a wide range of applications and is highly immune to false alarm sources
