Wavin Soil & Waste Systems – wastewater drainage for any building type

Wavin Soil and Waste portfolio covers individual domestic connections to complex commercial and industrial drainage stacks, the range is split into two tiers: Osma residential systems for domestic and light commercial applications, and a Commercial range for higher-specification projects where noise control, chemical resistance or enhanced performance are required.

Portfolio encompasses soil and vent pipes, waste and trap systems, self-sealing waterless traps, acoustic drainage, HDPE welded systems and solvent-weld alternatives.

System Composition

Product Families

1. Wavin OsmaSoil and Vent

A PVC-U soil and vent stack system for residential and commercial above-ground drainage. Available in push-fit (ring-seal) and solvent weld jointing, in three colours and multiple pipe diameters.

Sizes: Ring-seal push-fit available in 82mm, 110mm and 160mm; solvent weld available in 110mm and 160mm Colours: Black, grey and white

Key features:

• Co-moulded captive seal technology - seals are permanently retained in fittings and cannot dislodge, ensuring an airtight joint without manual alignment

• Unique keyway system - boss socket adaptors locate positively into a corresponding keyway, guaranteeing the correct fall is achieved every time

• Recycore Technology - 110mm and 160mm plain-ended and single-socketed soil pipes contain at least 50% recycled PVC-U (BS EN 1453-1 Kitemarked)

2. Wavin Osma Waste and Traps

Waste branch pipework range for connection to the OsmaSoil stack or other compatible systems, covering push-fit and solvent weld jointing, together with traps, overflows and condensate connections.

Key features:

• Available in push-fit and solvent weld variants

• Extensive fitting range: bends, tees, reducers, adaptors, inspection pieces, brackets, P-traps, S-traps, and condensate connections

• Available in grey, black and white to match OsmaSoil colour selection

• Over 320 individual products covering the full range of domestic plumbing configurations

3. Wavin Osma Hep_vO Self-Sealing Waste Valve

Hep_vO is a patented self-sealing waterless trap that prevents foul sewer gases entering a building without relying on a retained water seal. World's best-selling waterless trap, received a Top Product Award 2025.

Key features:

• Dry seal technology - elastomeric one-way membrane opens under waste flow and closes to create a seal; cannot fail through evaporation, siphonage, leaks or displacement

• One-way valve admits air, making it suitable for use as branch ventilation

• Compact in-line design for use in confined spaces and under-sink cupboards

• Installs vertically or horizontally; angled and running adaptors available

• Kitemarked; 15-year guarantee

4. Wavin AS+

Wavin AS+ an advanced plumbing system for wastewater drainage with superior noise reduction, enhanced performance and quick installation. Designed for any environment where quiet operation is critical, including apartments, residential developments, schools, universities, hospitals, hotels and offices.

Key features:

• Comprehensive sound reduction addressing airborne, structure-borne and structural sound transmission

• Achieved through high mass, high wall thickness, low elastic modulus material and specially designed brackets

• Patented self-lubricated blue seal - reduces the insertion force required to push pipes into fittings, accelerating installation in confined or awkward spaces

• Compatible with gravity-fed rainwater systems and high-temperature/greasy water environments such as commercial kitchens

Design tool: The Wavin SoundCheck Tool accurately predicts noise levels for any AS+ installation, covering both airborne and structure-borne sound, developed by specialist acoustic engineers.

5. Wavin HDPE Soil, Waste and Vent

A fully welded high-density polyethylene system for commercial and industrial applications where a permanently sealed, chemically resistant installation is required.

Pipe diameters: 40mm to 315mm (twelve sizes) Standards: Approved to DIN 19535 and DIN EN 1519 for building pipe installation

Key features:

• Jointing by butt welding or electrofusion

• Hand-held Duo 315 welder covers the complete diameter range with a single tool

• High chemical resistance - suitable for industrial effluent and aggressive waste streams

• Integrates with Wavin AS low-noise systems and QuickStream siphonic roof drainage

6. Wavin Solvent Soil and Wavin Solvent Waste and Traps

PVC-U solvent-weld soil and waste system for industrial and commercial projects where a compact, space-saving installation is required. The Solvent Waste and Traps range connects seamlessly to Wavin Solvent Soil and to Wavin AS.

Key features:

• Solvent weld jointing for a rigid, permanent connection

• Space-saving design for flexible routing in commercial installations

• Complementary trap, overflow and condensate ranges

• Suited to industrial and commercial wastewater drainage applications

Specification Support BIM Revit packages with 100% accurate content are available for the range. Design assistance is available from Wavin Design Services for complex or bespoke projects.

Applications

• Residential new build and refurbishment (domestic soil, waste and trap connections)

• Multi-occupancy residential, hotels, student accommodation and care homes (acoustic drainage)

• Schools, universities and hospitals (acoustic drainage and chemical resistance)

• Commercial kitchens and food production (high-temperature and grease-resistant drainage)

• Industrial facilities (HDPE welded systems for chemical resistance)

• Commercial and mixed-use developments (full range applicable)
