CronoLine-IL-E is an electronically controlled, glanded double pump with an in-line design, flange connection and automatic power adjustment.

It is used for pumping heating water (in accordance with VDI 2035), water-glycol mixtures and cooling and cold water without abrasive substances in heating, cold water and cooling water systems.

This single-stage, low-pressure centrifugal pump features:

  • Mechanical seal
  • Flange connection
  • Lantern
  • Coupling
  • Drive with integrated electronic speed control

Key features / advantages

  • Motors with IE2 technology for higher efficiency fitted as standard
  • Energy savings due to integrated electronic control
  • Simple operation with red-button technology and display
  • Integrated dual pump management
  • Two configurable signal relays for run and fault signals
  • Configurable fault response tailored to HVAC applications
  • Access disable on the pump
  • Integrated full motor protection (PTC thermistor sensor) with trip electronics
  • Functions and operation identical to Wilo-VeroLine-IP-E
  • High standard of corrosion protection thanks to cataphoretic coating
  • Condensate drainage holes as standard

Technical data

  • Permissible temperature range of -20 °C to +140 °C
  • Mains connection
  • 3~440 V ±10 %, 50/60 Hz
  • 3~400 V ±10 %, 50/60 Hz
  • 3~380 V -5 % +10 %, 50/60 Hz
  • Protection class IP 55
  • Nominal diameter DN 40 to DN 200
  • Max. operating pressure 16 bar

Materials

  • Pump housing and lantern: EN-GJL-250
  • Impeller
  • Standard version: EN-GJL-200
  • Special version: Bronze CuSn 10
  • Shaft: 1.4122
  • Mechanical seal: AQEGG; other mechanical seals on request
