Type Air cooled
Refrigerant R134a
Compressor type Centrifugal compressors
Nominal cooling capacity (kW) 259-861



TBX is a high chiller range with axial fans, compressors with magnetic levitation bearings and tube core exchangers.

Features:

  • Available in 12 sizes
  • Cooling only version
  • New generation two-stage oil-free centrifugal compressor with magnetic levitation bearings
  • Exceptional high efficiency at part load (up to 30% higher ESEER compared to standard chillers)
  • Electronic expansion valve for precise control
  • Flooded shell and tube evaporator optimised for refrigerant R134a
  • Axial fans for extremely quiet operation
  • Compressor features: 1. Operates without oil as bearings are magnetic levitation type. Vibration free and very quiet; 2. Provided with inverter technology that permits capacity modulation down to 25%; 3. Integrated controller that reduces starting current to 6A only
  • Standard “°” and Low noise “L” versions: 1. Operating limit up to 42°C external air temperature; 2. Compressor acoustical enclosure for low noise operation; 3. Fan speed control
  • High efficiency “A” and high efficiency low noise “E” versions: 1. Operating limit up to 42°C external air temperature; 2. Compressor acoustical enclosure for low noise operation; 3. EC (Electronically Commutated) fan
  • Modulating capacity control microprocessor system
  • Evaporator trace heating
  • LCD user interface: colour touch-screen with simple and intuitive graphical menu
  • Multilingual display panel
  • Compact sizes
  • Metal control panel with anti-corrosion polyester paint

Technical:

  • Cooling capacity: 259-861kW


TBX is a high chiller range with axial fans, compressors with magnetic levitation bearings and tube core exchangers.

Features:

  • Available in 12 sizes
  • Cooling only version
  • New generation two-stage oil-free centrifugal compressor with magnetic levitation bearings
  • Exceptional high efficiency at part load (up to 30% higher ESEER compared to standard chillers)
  • Electronic expansion valve for precise control
  • Flooded shell and tube evaporator optimised for refrigerant R134a
  • Axial fans for extremely quiet operation
  • Compressor features: 1. Operates without oil as bearings are magnetic levitation type. Vibration free and very quiet; 2. Provided with inverter technology that permits capacity modulation down to 25%; 3. Integrated controller that reduces starting current to 6A only
  • Standard “°” and Low noise “L” versions: 1. Operating limit up to 42°C external air temperature; 2. Compressor acoustical enclosure for low noise operation; 3. Fan speed control
  • High efficiency “A” and high efficiency low noise “E” versions: 1. Operating limit up to 42°C external air temperature; 2. Compressor acoustical enclosure for low noise operation; 3. EC (Electronically Commutated) fan
  • Modulating capacity control microprocessor system
  • Evaporator trace heating
  • LCD user interface: colour touch-screen with simple and intuitive graphical menu
  • Multilingual display panel
  • Compact sizes
  • Metal control panel with anti-corrosion polyester paint

Technical:

  • Cooling capacity: 259-861kW
