Suitability Contaminated / brownfield land
Material Steel
Product accreditation BS EN 12201-2:2003
WRAS approved
Diameter (mm) 80-3000



FT Pipeline Systems supplies steel water pipes throughout the UK in 80-3000mm diameters. A range of coating, lining and jointing options are available to suit the requirements of each individual project.

Steel pipes are supplied in 6m, 9m, 12m and 13.5m lengths, or special lengths up to 18m on request.

Key features:

  • Regulations DWI 31 (4) (a) and DWI 25 (1) (a) approved
  • Suitable for all ground conditions including contaminated or rocky sites.
  • Ideal for use in brownfield and high pressure situations.
  • No additional external wrapping required
  • 3 layer PE corrosion protection required
  • WRC approvals

SAW spirally / longitudinally welded pipe steel specifications:

  • Steel grade ST37, L235 API 5L Grade B, X42, X52 and L275
  • Yield strength, 235N/mm2 to BS 534.
  • Test certification to EN 10204/3, 1B
  • Steel grade X60, P235 or P275 on request.


FT Pipeline Systems supplies steel water pipes throughout the UK in 80-3000mm diameters. A range of coating, lining and jointing options are available to suit the requirements of each individual project.

Steel pipes are supplied in 6m, 9m, 12m and 13.5m lengths, or special lengths up to 18m on request.

Key features:

  • Regulations DWI 31 (4) (a) and DWI 25 (1) (a) approved
  • Suitable for all ground conditions including contaminated or rocky sites.
  • Ideal for use in brownfield and high pressure situations.
  • No additional external wrapping required
  • 3 layer PE corrosion protection required
  • WRC approvals

SAW spirally / longitudinally welded pipe steel specifications:

  • Steel grade ST37, L235 API 5L Grade B, X42, X52 and L275
  • Yield strength, 235N/mm2 to BS 534.
  • Test certification to EN 10204/3, 1B
  • Steel grade X60, P235 or P275 on request.
