The FCL cassette type fan coil is a terminal for the conditioning of air in a room. It concentrates high technological and functional features that make it the ideal means for air conditioning for all environments.

FCL generates heat if included in a heating system with boiler or heat pump but may also be used in the summer as an air conditioner if the heating system has a water chiller.

The unit is mounted in a suspended ceiling with the possibility of sending conditioned air to adjacent rooms and introducing external air independently from unit ventilation.

Features:

Available in two versions, for two- and four-pipe systems
Standard preparation with internal three-way valve, fast connection actuator and position visual signalling
FCL_V2 preparation (upon request), with internal two-way valve, suitable for variable water flow rate systems
FCL_VL preparation (upon request), without internal valve
3 configurations on one cassette type fan coil
High design aesthetics
Low sound emissions
3-speed and 4-speed axial-centrifuge fan unit for larger sizes
Load-bearing structure reinforced with a galvanised steel side band
Internal elements insulated with expanded polystyrene obtained in injection presswork for noise reduction and air routing
Condensation drip tray in one piece, with V0 self-extinguishing level and overmoulding to insulation in expanded polystyrene with flame retardant additive
Thermal exchanger with shaped profile to increase exchange surface
Continuous fan operation to prevent stratification of room air
Possibility of direct release of external air regardless of indoor unit ventilation
Possibility to control the climate of adjacent rooms
Air filter easily removed and cleaned
Electrostatically pre-charged air filter regenerated with class-2 fire resistance (UL 900)
Full compliance with safety regulations
Easy installation and maintenance

Technical:

Cooling capacity: 1900-11000W
Heating capacity: 2300-13000W

FCL fan coil unit for suspended ceilings
