AMCA-certified architectural louvres by Construction Specialties are made for airflow control and rain defence in building façades. Independently tested to ANSI/AMCA Standard 500-L and EN 13030, these louvres are available in 15 models, including weather and ventilation types, with ongoing performance validation and options for high-velocity wind-driven rain resistance.

  • Architectural louvres for airflow management and rain protection in external walls
  • Independently certified to AMCA and EN 13030 standards for verified performance
  • 15 models including weather louvres for wind-driven rain and ventilation louvres for maximum airflow
  • Ongoing compliance audits maintain accuracy of published performance data
  • Options include double-bank, modular, and bold line designs for varied façade aesthetics
  • Some models AMCA 550 listed for high-velocity wind-driven rain resistance
  • Depths range from 82mm to 131mm depending on model

Applications

  • External building façades requiring controlled airflow and rain defence, such as data centres, curtain walling, and high-level applications

Options and variations

RS-5215 Rain Defence Louvres: compact double-bank, continuous blade, very good airflow

RS-5225 Rain Defence Louvres: compact double-bank, inverted front blades for sightproofing

A-6177 Ventilation Louvres: modular, high airflow for mechanical extract systems

RS-4605 Rain Defence Louvres: 106mm deep, high-performance, shallow openings

RS-3900 Rain Defence Louvres: 82mm deep, high-performance, very good airflow

B-6485 Ventilation Louvres: bold line, two blade depths, customisable façade design

B-7505 Rain Defence Louvres: bold line, two blade depths, customisable façade design

RS-5900 Rain Defence Louvres: 130mm deep, maximum rain protection, very good airflow

RS-5605 Rain Defence Louvres: 131mm deep, maximum rain protection, excellent airflow

RSV-5700 Rain Defence Louvres: 129mm deep, excellent rain protection, good airflow

RSH-5700 Rain Defence Louvres: 129mm deep, excellent rain protection, good airflow

A-4080/A-4085 Ventilation Louvres: modular ventilation louvres

Performance

Tested to ANSI/AMCA Standard 500-L for airflow, pressure drop, water penetration, and wind-driven rain resistance

AMCA 550 listed models resist high-velocity wind-driven rain

Product accreditations

AMCA Certified Ratings Program (CRP)

EN 13030 tested

AMCA 550 listed (select models)
