Product name VeroLine-IP-E
Suitability Cooling systems
Heating systems
Housing Cast iron
Max. pressure 10 bar (special version: 16 bar)
Liquid temperature range (deg. C) -20 °C to +120 °C




VeroLine-IP-E is an electronically controlled glanded double pump in in-line design with flange connection and automatic power adjustment.

It is used for pumping heating water (in accordance with VDI 2035), water-glycol mixtures and cooling and cold water without abrasive substances in heating, cold water and cooling water systems.

Key features / advantages

  • Motors with higher efficiency as standard; motors with IE2 technology if rated motor power is 0.75 kW or more
  • Energy savings due to integrated electronic control
  • Simple operation with red-button technology and display
  • Integrated dual pump management
  • Two configurable signal relays for run and fault signals
  • Configurable fault response tailored to HVAC applications
  • Access disable on the pump
  • Integrated full motor protection (PTC thermistor sensor) with trip electronics
  • Functions and operation identical to Wilo-CronoLine-IL-E
  • High standard of corrosion protection thanks to cataphoretic coating
  • Condensate drainage holes as standard


VeroLine-IP-E is an electronically controlled glanded double pump in in-line design with flange connection and automatic power adjustment.

It is used for pumping heating water (in accordance with VDI 2035), water-glycol mixtures and cooling and cold water without abrasive substances in heating, cold water and cooling water systems.

Key features / advantages

  • Motors with higher efficiency as standard; motors with IE2 technology if rated motor power is 0.75 kW or more
  • Energy savings due to integrated electronic control
  • Simple operation with red-button technology and display
  • Integrated dual pump management
  • Two configurable signal relays for run and fault signals
  • Configurable fault response tailored to HVAC applications
  • Access disable on the pump
  • Integrated full motor protection (PTC thermistor sensor) with trip electronics
  • Functions and operation identical to Wilo-CronoLine-IL-E
  • High standard of corrosion protection thanks to cataphoretic coating
  • Condensate drainage holes as standard
