Radiator valves

(46)

Thermostatic radiator valves (TRV) consist of two parts: a sensor and a valve. The sensor monitors room temperature and adjusts the valve in order to control the flow of hot water to the radiator. If it’s too cold, it increases the flow, and if it’s too hot it shuts it off. Read More

Most TRVs are set manually, although they can also be controlled digitally. Their key benefit is reduced energy costs: the radiator is only on if the room temperature falls below the designated level.

Separate thermostat heads are also available. Some have remote sensors, allowing the room temperature to be monitored at a distance from the radiator.

Unlike TRVs, which are termed 'set and forget' valves, manual radiator valves need to be continually turned up or down if a constant temperature is to be maintained.

The likelihood that someone forgets to turn a valve down if a room is too warm or not being used is the main reason for their relative energy inefficiency.

Their major advantage is that they are smaller, and the distinct aesthetic that contemporary or retro versions give is not compromised by the thermostat.

Lockshield valves are used to balance central heating systems. They also allow individual radiators to be shut off for maintenance without affecting the rest of the system.

Read Less

Radiator valves - helping you find the best solution for your project.

  • GP lockshield return valve

    Visit site
    GP lockshield return valve
    The GP lockshield return valve is made to DIN 3842 and has five functions: connecting, closing, pre-setting, filling and draining. It is used for hot water heating systems. Universal models are equipped with special sockets that either connect a threaded pipe or a calibrated soft steel or copper pipe, the latter two by means of compression union
    Visit site More info

  • GP wheelhead radiator control valve

    Visit site
    GP wheelhead radiator control valve
    The GP wheelhead radiator control valve features pre-setting by means of a limiting valve lift. Both straight and angled models are available. Universal models are nickel-plated and equipped with special sockets for threaded pipe and compression union connections. GP valves are equipped with special sockets for connection to either a threaded pipe
    • PRODUCT
    • Herz Valves UK
    Visit site More info

  • RL-1-E single-pipe return valves

    Visit site
    RL-1-E single-pipe return valves
    RL-1-E single-pipe return valves are suitable for water heating systems. They are available in straight and angled versions. Standard models have nickel plated threaded sockets. The valve is shut-off or opened by turning the spindle by means of the Herz multi-purpose key or an 8mm Allen key. The return valve permits the shut-off of the return
    Visit site More info

  • DE LUXE return valves

    Visit site
    DE LUXE return valves
    The DE LUXE return valve allows shut-off on a radiator return connection. When both the intake and return valves are shut-off (thermostatic head in position 0) the radiator can be removed while the system is under pressure, without having to close off the rest of the system. The return valve ensures exact control of the water flow rate through the
    Visit site More info

  • Return valve with knurled cap

    Visit site
    Return valve with knurled cap
    Herzs bi-directional valves can be installed as either a vertical or horizontal thermostatic valve. Features include: Bi-directional flow. Stylish liquid filled sensor. Five-year warranty. Conforms to EN 215 6-28°C temperature range. 8, 10 and 15mm sizes. Valves can be supplied either individually or as a set. Two return valve are available: the
    Visit site More info

  • DE LUXE thermostatic valve

    Visit site
    DE LUXE thermostatic valve
    The DE LUXE thermostatic valve is used for water heating applications. The upper part of the valve can be removed and/or changed by means of the HERZ changing tool while the system is under pressure. An O-ring is used as a spindle seal. It is located in a brass chamber that can be changed during operation. The O-ring ensures excellent valve
    Visit site More info

  • Radiator Valves - Pipes from the floor

    Visit site
    Radiator Valves - Pipes from the floor
    JIS Europe offer a range of valves for pipe from the floor. The range complements the Sussex range of radiators and heated towel rails. The range is available in the highest quality chrome plated brass and available in a polished or satin finish: Solar Straight Valves - Chrome plated brass Straight TRVs - Chrome plated thermostatic valves Square
    Visit site More info

  • LST thermostatic valve set

    Visit site
    LST thermostatic valve set
    The LST thermostatic valve set contains: A Herz thermostatic sensor. An angled thermostatic valve body. A retaining nut and washer that are attached to a plunger and capillary assembly. A plunger and capillary assembly. A set of compression fittings. The thermostatic valve automatically controls the temperature of a room by regulating the heating
    Visit site More info

  • Heimeier Mikrotherm manual radiator valves

    Visit site
    Heimeier Mikrotherm manual radiator valves
    The Heimeier Mikrotherm manual radiator valve is suitable for pump heating systems as well as gravity or low pressure steam systems. The valve is made from corrosion-resistant gunmetal and has a white plastic hand wheel cap. It is supplied in angled and straight versions, which makes it suitable for a range of applications. It can be retrofitted
    Visit site More info

  • Radiator Valves - Pipes from the wall

    Visit site
    Radiator Valves - Pipes from the wall
    JIS Europe offer a range of radiator / towel rail valves for pipes from the wall. The range includes: Solar Angled Valves - Highest quality chrome plated brass valves. Available with a polished or satin finish. Profile Valves -Sits neatly within the towel rail dimensions. Available with a polished or satin finish. Not suitable for dual fuel
    Visit site More info

  • Drain-off lockshield return valve

    Visit site
    Drain-off lockshield return valve
    Herzs bi-directional valves can be installed as either a vertical or horizontal thermostatic valve. Features include: Bi-directional flow. Stylish liquid filled sensor. Five-year warranty. Conforms to EN 215 6-28°C temperature range. 8, 10 and 15mm sizes. Valves can be supplied either individually or as a set. Two return valve are available: the
    Visit site More info

  • DR lockshield radiator control valve

    Visit site
    DR lockshield radiator control valve
    The DR lockshield radiator valve has five functions: connecting, closing, presetting, filling and draining. It is made to DIN 3842. Closing is performed by means of a valve spindle, which can be turned to open or close by means of a multipurpose key. The valve cone opening can be limited by means of the inner spindle, resulting in several finely
    Visit site More info

  • DR wheelhead radiator valve

    Visit site
    DR wheelhead radiator valve
    The DR wheelhead radiator control valve has a pre-setting function using a double cone, which is also suitable for thermostatic operation. A straight and angled model is available, and all are nickel plated, with a white screw disk and handwheel protection caps. The valve is suitable for hot water heating systems where high-precision adjustment
    Visit site More info

  • Mini Design Thermostatic Sensor

    Visit site
    Mini Design Thermostatic Sensor
    Herzs bi-directional valves can be installed as either a vertical or horizontal thermostatic valve. Features include: Bi-directional flow. Stylish liquid filled sensor. Five-year warranty. Conforms to EN 215 6-28°C temperature range. 8, 10 and 15mm sizes. Valves can be supplied either individually or as a set. A compact mini sensor, with a length
    Visit site More info

  • TS-90 thermostatic valves

    Visit site
    TS-90 thermostatic valves
    TS-90 thermostatic valves are suitable for water heating systems, and are available in straight and angled versions. All models are nickel plated and supplied with a screw cap. The universal models are equipped with special sockets that offer the option of connecting either a threaded pipe or calibrated soft steel or copper pipe, the latter two by
    Visit site More info

Radiator valves - helping you find the best companies for your project.
