Cold Water Booster Pumps and Sets - iBolt

Aquaboost iBolt booster pumps and single / twin pump booster sets

The Aquaboost iBolt range of booster pumps features a horizontal multistage pump controlled by an air-cooled variable speed frequency invertor mounted directly on the pump motor.

Aquaboost iBolt booster pump sets 03, 05, 09 range

The single pump 03 range includes 0304, 0306 and 0308 pump variants capable of delivering flow rates up to 5.0 m³/hour and capable of producing head pressures of up to 9.0 bar.

The single pump 05 range includes 0504, 0506 and 0508 pump variants capable of delivering flow rates up to 8.0 m³/hour and capable of producing head pressures of up to 9.2 bar.

The single pump 09 range includes 0903, 0904 and 0906 pump variants capable of delivering flow rates up to 15.0 m³/hour and capable of producing head pressures of up to 7.1 bar.

Range options

  • Aquaboost iBolt Pump 0304 47345 3.0 bar
  • Aquaboost iBolt Pump 0504 47347 3.4 bar
  • Aquaboost iBolt Pump 0903 47380 2.6 bar

Key Features

  • Flow rates up to 5.0 m³/h
  • Head pressure up to 4.4 bar
  • 304 stainless steel pump
  • Dry run protection
  • Stainless steel / brass discharge fittings
  • Nickel plated WRAS approved ball valves
  • Air cooled invertor
  • BMS volt free contacts
  • Hydraulic kit, base plate and anti-vibration mount options available



Aquaboost iBolt single pump booster sets 03, 05, 09 range

The single pump 03 range includes 0304, 0306 and 0308 pump variants capable of delivering flow rates up to 5.0 m³/hour and capable of producing head pressures of up to 9.0 bar.

The single pump 05 range includes 0504, 0506 and 0508 pump variants capable of delivering flow rates up to 8.0 m³/hour and capable of producing head pressures of up to 9.2 bar.

The single pump 09 range includes 0903, 0904 and 0906 pump variants capable of delivering flow rates up to 15.0 m³/hour and capable of producing head pressures of up to 7.1 bar.

Range options

  • Aquaboost iBolt 0304 1H-CMT/8 47381 3.0 bar
  • Aquaboost iBolt 0504 1H-CMT/8 47384 3.4 bar
  • Aquaboost iBolt 0903 1H-CMT/8 47387 2.6 bar

Key Features

  • Flow rates up to 5.0 m³/h
  • Head pressure up to 4.4 bar
  • 304 stainless steel pump
  • Dry run protection
  • Stainless steel / brass discharge fittings
  • Nickel plated WRAS approved ball valves
  • Air cooled invertor
  • BMS volt free contacts
  • Glycerine filled pressure gauge
  • Brass non-return valve
  • WRAS approved union ball valves
  • WRAS approved 8 litre pressure vessel

Aquaboost iBolt twin pump booster sets 03, 05, 09 range

The twin pump 03 range includes 0304, 0306 and 0308 pump variants capable of delivering flow rates up to 5.0 m³/hour (per pump) and capable of producing head pressures of up to 9.0 bar.

The twin pump 05 range includes 0504, 0506 and 0508 pump variants capable of delivering flow rates up to 8.0 m³/hour (per pump) and capable of producing head pressures of up to 9.2 bar.

Range options

  • Aquaboost iBolt 0304 2H-CMT/24 47353 3.0 bar
  • Aquaboost iBolt 0504 2H-CMT/24 47355 3.4 bar
  • Aquaboost iBolt 0903 2H-CMT/24 47392 2.6 bar

Key Features

  • Flow rates up to 16.0 m³/h
  • Head pressure up to 4.6 bar
  • 304 stainless steel pumps
  • Dry run protection
  • 304/316 stainless steel manifold assembly
  • Nickel plated WRAS approved ball valves
  • Air cooled invertor
  • BMS volt free contacts
  • Glycerine filled pressure gauge
  • Powder coated base plate
  • Union fittings on suction and discharge
  • WRAS approved 24 litre pressure vessel


Cold Water Booster Pumps and Sets - iBolt

Aquaboost iBolt booster pumps and single / twin pump booster sets

The Aquaboost iBolt range of booster pumps features a horizontal multistage pump controlled by an air-cooled variable speed frequency invertor mounted directly on the pump motor.

Aquaboost iBolt booster pump sets 03, 05, 09 range

The single pump 03 range includes 0304, 0306 and 0308 pump variants capable of delivering flow rates up to 5.0 m³/hour and capable of producing head pressures of up to 9.0 bar.

The single pump 05 range includes 0504, 0506 and 0508 pump variants capable of delivering flow rates up to 8.0 m³/hour and capable of producing head pressures of up to 9.2 bar.

The single pump 09 range includes 0903, 0904 and 0906 pump variants capable of delivering flow rates up to 15.0 m³/hour and capable of producing head pressures of up to 7.1 bar.

Range options

  • Aquaboost iBolt Pump 0304 47345 3.0 bar
  • Aquaboost iBolt Pump 0504 47347 3.4 bar
  • Aquaboost iBolt Pump 0903 47380 2.6 bar

Key Features

  • Flow rates up to 5.0 m³/h
  • Head pressure up to 4.4 bar
  • 304 stainless steel pump
  • Dry run protection
  • Stainless steel / brass discharge fittings
  • Nickel plated WRAS approved ball valves
  • Air cooled invertor
  • BMS volt free contacts
  • Hydraulic kit, base plate and anti-vibration mount options available



Aquaboost iBolt single pump booster sets 03, 05, 09 range

The single pump 03 range includes 0304, 0306 and 0308 pump variants capable of delivering flow rates up to 5.0 m³/hour and capable of producing head pressures of up to 9.0 bar.

The single pump 05 range includes 0504, 0506 and 0508 pump variants capable of delivering flow rates up to 8.0 m³/hour and capable of producing head pressures of up to 9.2 bar.

The single pump 09 range includes 0903, 0904 and 0906 pump variants capable of delivering flow rates up to 15.0 m³/hour and capable of producing head pressures of up to 7.1 bar.

Range options

  • Aquaboost iBolt 0304 1H-CMT/8 47381 3.0 bar
  • Aquaboost iBolt 0504 1H-CMT/8 47384 3.4 bar
  • Aquaboost iBolt 0903 1H-CMT/8 47387 2.6 bar

Key Features

  • Flow rates up to 5.0 m³/h
  • Head pressure up to 4.4 bar
  • 304 stainless steel pump
  • Dry run protection
  • Stainless steel / brass discharge fittings
  • Nickel plated WRAS approved ball valves
  • Air cooled invertor
  • BMS volt free contacts
  • Glycerine filled pressure gauge
  • Brass non-return valve
  • WRAS approved union ball valves
  • WRAS approved 8 litre pressure vessel

Aquaboost iBolt twin pump booster sets 03, 05, 09 range

The twin pump 03 range includes 0304, 0306 and 0308 pump variants capable of delivering flow rates up to 5.0 m³/hour (per pump) and capable of producing head pressures of up to 9.0 bar.

The twin pump 05 range includes 0504, 0506 and 0508 pump variants capable of delivering flow rates up to 8.0 m³/hour (per pump) and capable of producing head pressures of up to 9.2 bar.

Range options

  • Aquaboost iBolt 0304 2H-CMT/24 47353 3.0 bar
  • Aquaboost iBolt 0504 2H-CMT/24 47355 3.4 bar
  • Aquaboost iBolt 0903 2H-CMT/24 47392 2.6 bar

Key Features

  • Flow rates up to 16.0 m³/h
  • Head pressure up to 4.6 bar
  • 304 stainless steel pumps
  • Dry run protection
  • 304/316 stainless steel manifold assembly
  • Nickel plated WRAS approved ball valves
  • Air cooled invertor
  • BMS volt free contacts
  • Glycerine filled pressure gauge
  • Powder coated base plate
  • Union fittings on suction and discharge
  • WRAS approved 24 litre pressure vessel





Downloads
  • Aquaboost iBolt single pump range
    Aquaboost iBolt single pump range
    12pp 1.31MB
    Download
  • Aquaboost iBolt pump range
    Aquaboost iBolt pump range
    12pp 1.3MB
    Download
  • Aquaboost iBolt twin pump range
    Aquaboost iBolt twin pump range
    12pp 1.5MB
    Download
